The Gandiva Expression Compiler¶

Gandiva is a runtime expression compiler that uses LLVM to generate efficient native code for projections and filters on Arrow record batches. Gandiva only handles projections and filters. For other transformation, see Compute Functions.

Gandiva was designed to take advantage of the Arrow memory format and modern hardware. Compiling expressions using LLVM allows the execution to be optimized to the local runtime environment and hardware, including available SIMD instructions. To minimize optimization overhead, all Gandiva functions are pre-compiled into LLVM IR (intermediate representation).

Building Expressions¶

Gandiva provides a general expression representation where expressions are represented by a tree of nodes. The expression trees are built using gandiva::TreeExprBuilder. The leaves of the expression tree are typically field references, created by gandiva::TreeExprBuilder::MakeField(), and literal values, created by gandiva::TreeExprBuilder::MakeLiteral(). Nodes can be combined into more complex expression trees using:

gandiva::TreeExprBuilder::MakeFunction() to create a function node. See available functions below.

gandiva::TreeExprBuilder::MakeIf() to create if-else logic.

gandiva::TreeExprBuilder::MakeAnd() and gandiva::TreeExprBuilder::MakeOr() to create boolean expressions. (For “not”, use the not(bool) function in MakeFunction.)

gandiva::TreeExprBuilder::MakeInExpressionInt32() and the other “in expression” functions to create set membership tests.

Once an expression tree is built, they are wrapped in either gandiva::Expression or gandiva::Condition, depending on how they will be used. Expression is used in projections while Condition is used filters.

As an example, here is how to create an Expression representing x + 3 and a Condition representing x < 3:

auto field_x_raw = arrow::field("x", arrow::int32());
auto field_x = TreeExprBuilder::MakeField(field_x_raw);
auto literal_3 = TreeExprBuilder::MakeLiteral(3);
auto field_result = arrow::field("result", arrow::int32());

auto add_node = TreeExprBuilder::MakeFunction("add", {field_x, literal_3}, arrow::int32());
auto expression = TreeExprBuilder::MakeExpression(add_node, field_result);

auto less_than_node = TreeExprBuilder::MakeFunction("less_than", {field_x, literal_3},
                                                    boolean());
auto condition = TreeExprBuilder::MakeCondition(less_than_node);

For simpler expressions, there are also convenience functions that allow you to use functions directly in MakeExpression and MakeCondition:

auto expression = TreeExprBuilder::MakeExpression("add", {field_x, literal_3}, field_result);

auto condition = TreeExprBuilder::MakeCondition("less_than", {field_x, literal_3});

Projectors and Filters¶

Gandiva’s two execution kernels are gandiva::Projector and gandiva::Filter. Projector consumes a record batch and projects into a new record batch. Filter consumes a record batch and produces a gandiva::SelectionVector containing the indices that matched the condition.

For both Projector and Filter, optimization of the expression IR happens when creating instances. They are compiled against a static schema, so the schema of the record batches must be known at this point.

Continuing with the expression and condition created in the previous section, here is an example of creating a Projector and a Filter:

auto schema = arrow::schema({field_x});
std::shared_ptr<Projector> projector;
auto status = Projector::Make(schema, {expression}, &projector);
ARROW_CHECK_OK(status);

std::shared_ptr<Filter> filter;
status = Filter::Make(schema, condition, &filter);
ARROW_CHECK_OK(status);

Once a Projector or Filter is created, it can be evaluated on Arrow record batches. These execution kernels are single-threaded on their own, but are designed to be reused to process record batches in parallel.

Execution is performed with gandiva::Projector::Evaluate() and gandiva::Filter::Evaluate(). Filters produce gandiva::SelectionVector, a vector of row indices that matched the filter condition. When filtering and projecting record batches, you can pass the selection vector into the projector so that the projection is only evaluated on matching rows.

Here is an example of evaluating the Filter and Projector created above:

auto pool = arrow::default_memory_pool();
int num_records = 4;
auto array = MakeArrowArrayInt32({1, 2, 3, 4}, {true, true, true, true});
auto in_batch = arrow::RecordBatch::Make(schema, num_records, {array});

// Just project
arrow::ArrayVector outputs;
status = projector->Evaluate(*in_batch, pool, &outputs);
ARROW_CHECK_OK(status);

// Evaluate filter
gandiva::SelectionVector result_indices;
status = filter->Evaluate(*in_batch, &result_indices);
ARROW_CHECK_OK(status);

// Project with filter
arrow::ArrayVector outputs_filtered;
status = projector->Evaluate(*in_batch, selection_vector.get(),
                             pool, &outputs_filtered);

Available Gandiva Functions¶

Common Types¶

To be succinct, we describe the types in the following groups:

Integer: int8, int16, int32, int64, uint8, uint16, uint32, uint64

Float: float, double

Decimal: decimal128

Numeric: Integer or Float or Decimal

Date: date64[ms], date32[day]

Time: time32[ms]

Timestamp: timestamp[ms]

When we wrap the input types in parentheses, that means those inputs must be in that order.

Warning

Functions that take decimals and return decimals do not currently respect or enforce the scale and precision of the provided return type. For example, add(decimal(28, 4), decimal(28, 3)) will always return a decimal(28, 4), so if you specify a return type decimal(28, 3) the resulting array will have incorrect results. It is up to the user to match the return type with the expectations of the functions.

Comparisons¶

Function names	Arity	Input types	Output type	Notes
not	Unary	`bool`	`bool`
isnull, isnotnull	Unary	Any	`bool`
equal, eq, same,	Binary	Any	`bool`	(1)
is_distinct_from, is_not_distinct_from	Binary	Any	`bool`	(2)
less_than, less_than_or_equal_to, greater_than, greater_than, greater_than_or_equal_to	Binary	Any	`bool`

(1) eq and same are aliases for equal.
(2) is_not_distinct_from is the “NULL-safe” version of equal, meaning it will treat two NULL values as equal, while equal considers NULL values as unknown and never equal.

Casting and Conversion¶

Casts convert values between types. These may raise errors, for example if casting between numeric types causes overflow or if attempting to cast an invalid date string to a date type.

Function names	Arity	Input types	Output type	Notes
castBIGINT	Unary	`int32`, `decimal128`, `day_time_interval`, `string`	`int64`	(1)
castINT	Unary	`int64`, `string`	`int32`
castFLOAT4	Unary	`int32`, `int64`, `double`, `string`	`float`
castFLOAT8	Unary	`int32`, `int64`, `float`, `decimal128`, `string`	`double`
castDECIMAL, castDECIMALNullOnOverflow	Unary	`int32`, `int64`, Float, `decimal128`, `string`	`decimal128`
castDATE	Unary	`int64`, `date32[day]`, `timestamp[ms]`, `string`	`date64[ms]`	(2)
castDATE	Unary	`int32`	`date32[day]`	(3)
castTIME	Unary	`timestamp[ms]`	`time32[ms]`
castTIMESTAMP	Unary	`string`, `date64[ms]`, `int64`	`timestamp[ms]`
castVARCHAR	Binary	(Any, `int64`)	`string`	(4)
castVARBINARY	Binary	(Any, `int64`)	`binary`	(4)
castBIT, castBOOLEAN	Unary	`string`	`bool`	(5)
to_time	Unary	Numeric	`time32[ms]`	(6)
to_timestamp	Unary	Numeric	`timestamp[ms]`	(7)
to_date	Unary	`timestamp[ms]`	`date64[ms]`	(7)
to_date	Binary	(`string`, `string`)	`date64[ms]`	(8)
to_date	Ternary	(`string`, `string`, `int32`)	`date64[ms]`	(8)
convert_toDOUBLE, convert_toDOUBLE_be, convert_toFLOAT, convert_toFLOAT_be, convert_toINT, convert_toINT_be, convert_toBIGINT, convert_toBIGINT_be, convert_toBOOLEAN_BYTE, convert_toTIME_EPOCH, convert_toTIME_EPOCH_be, convert_toTIMESTAMP_EPOCH, convert_toTIMESTAMP_EPOCH_be, convert_toDATE_EPOCH, convert_toDATE_EPOCH_be, convert_toUTF8	Unary	`double`, `float`, `int32`, `int64`, `bool`, `string`, `date[ms]`, `timestamp[ms]`	`binary`	(9)
convert_fromUTF8, convert_fromutf8	Unary	`binary`	`string`
convert_replaceUTF8, convert_replaceutf8	Binary	(`binary`, `string`)	`string`	(10)

(1) castBIGINT(day_time_interval) -> int64 returns the number of milliseconds in interval.
(2) castDATE(int64) -> date64[ms] returns the date using input as milliseconds since UNIX epoch 1970-01-01.
(3) castDATE(int32) -> date32[ms] returns the date using input as days since UNIX epoch 1970-01-01.
(4) For castVARCHAR and castVARBINARY, the second parameter (of type int64) represents the maximum number of bytes to return. If the string representation of the value is larger then that specified max, the result will be truncated. For example, castVARCHAR("12345", 3) would return 123.
(5) castBOOLEAN is an alias for castBIT. Converts "true" or "1" to true and "false" or "0" to false.
(6) to_time takes a timestamp in seconds and converts into a time, dropping the date information.
(7) to_timestamp returns the timestamp using input as milliseconds since UNIX epoch 1970-01-01.
(8) to_date(string, string [, int32]) parses the first string into a date based on the format string specified in the string parameter. The optional int32 parameter indicates to suppress errors, which is turned on with value 1.
(9) variants that end in _be return bytes in big endian order, while main variant returns in platform-native endianness.
(10) The “replace” variations take a second string parameter which is the character to replace any bytes that are not valid Unicode with.

Arithmetic¶

Function names	Arity	Input types	Output type	Notes
add	Binary	Numeric	Numeric
subtract	Binary	Numeric	Numeric
multiply	Binary	Numeric	Numeric
divide	Binary	Numeric	Numeric
mod, modulo	Binary	Integer, `double`, `decimal128`	Integer, `double`, `decimal128`	(1)
div	Binary	Integer, Float	Integer, Float	(2)
bitwise_and, bitwise_or, bitwise_xor	Binary	Integer	Integer
bitwise_not	Unary	Integer	Integer

(1) modulo is an alias for mod.
(2) div performs integer division, which for Integer types is identical to divide, but for float types will truncate to the closest integer it is not greater than.

Math¶

Function names	Arity	Input types	Output type	Notes
cbrt, exp, log, log10	Unary	Integer, Float	`double`
log	Binary	(Integer or Float, Integer or Float)	`double`	(1)
power, pow	Binary	(`double`, `double`)	`double`	(2)
sin, cos, tan, asin, acos, atan, sinh, cosh, tanh, cot, atan2	Unary	Integer, Float	`double`
radians, degrees	Unary	Integer, Float	`double`	(3)
random, rand	Nullary	None	`double`	(4)
random, rand	Unary	`int32`	`double`	(4)

(1) The binary log function uses the first parameter as the base and the second as the operand. In other words log(a, b) = log(b) / log(a).
(2) pow is an alias for power.
(3) radians converts degrees to radians and degrees converts the other way.
(4) rand is an alias for random. The unary version takes an int32 seed. Both versions return a 64-bit float in the range of [0, 1).

Rounding¶

Function names	Arity	Input types	Output type	Notes
round	Unary	Numeric	Numeric
round	Binary	(Numeric, `int32`)	Numeric	(1)
abs, ceil, floor	Unary	Decimal	Decimal
truncate, trunc	Unary	Decimal	Decimal	(2)
truncate, trunc	Binary	(Decimal or `int64`, `int32`)	`int32`, Decimal	(2) (3)

(1) The second parameter (of type int32) is the precision, with positive values rounding to places right of the decimal and negative to the left. For example, round(123.456, 2) returns 123.46 and round(123.456, -2) returns 100.0.
(2) trunc is an alias for truncate.
(3) The second parameter (of type int32) is the precision, which works similarly to the precision parameter of round.

Date and Time¶

Function names	Arity	Input types	Output type	Notes
add, date_add	Binary	Integer, `date64[ms]`, `timestamp[ms]`	`date64[ms]`, `timestamp[ms]`	(1)
subtract, date_sub, date_diff	Binary	(`date64[ms]` or `timestamp[ms]`, Integer)	`date64[ms]`, `timestamp[ms]`	(1)
extractMillennium, extractCentury, extractDecade, extractYear, extractQuarter, extractMonth, extractWeek, extractDay, extractHour, extractMinute, extractSecond, extractDoy, extractDow, extractEpoch	Unary	`date64[ms]`, `timestamp[ms]`	`int64`	(2)
date_trunc_Millennium, date_trunc_Century, date_trunc_Decade, date_trunc_Year, date_trunc_Quarter, date_trunc_Month, date_trunc_Week, date_trunc_Day, date_trunc_Hour, date_trunc_Minute, date_trunc_Second	Unary	`date64[ms]`, `timestamp[ms]`	`int64`
last_day	Unary	`date64[ms]`, `timestamp[ms]`	`date64[ms]`
months_between	Binary	`date64[ms]`, `timestamp[ms]`	`double`
timestampdiffSecond, timestampdiffMinute, timestampdiffHour, timestampdiffDay, timestampdiffWeek, timestampdiffMonth, timestampdiffQuarter, timestampdiffYear	Binary	`timestamp[ms]`	`double`
timestampaddSecond, timestampaddMinute, timestampaddHour, timestampaddDay, timestampaddWeek, timestampaddMonth, timestampaddQuarter, timestampaddYear	Binary	`timestamp[ms]`	`double`

(1) In add and subtract, the integer parameter represents the number of days to add or subtract from the give date or timestamp. date_add is an alias for add and date_sub and date_diff are aliases for subtract.
(2) year is an alias for extractYear, month an alias for extractMonth, weekofyear and yearweek aliases for extractWeek, day and dayofmonth aliases of extractDay, hour an alias for extractHour, minute an alias for extractMinute, and second an alias for extractSecond.

String Manipulation¶

Function names	Arity	Input types	Output type	Notes
bin	Unary	`int32`, `int64`	`string`	(1)
space	Unary	`int32`, `int64`	`string`	(2)
starts_with, ends_with, is_substr	Binary	`string`	`bool`
like, ilike	Binary	`string`	`bool`
like	Ternary	`string`	`bool`	(3)
locate, position	Binary	`string`	`int32`	(4)
locate, position	Ternary	(`string`, `string`, `int32`)	`int32`	(4)
octet_length, bit_length	Unary	`string`, `binary`	`int32`
char_length, length	Unary	`string`	`int32`
lengthUtf8	Unary	`binary`	`int32`
reverse, ltrim, rtrim, btrim	Unary	`string`	`string`
ltrim, rtrim, btrim	Binary	`string`	`string`	(5)
ascii	Unary	`string`	`int32`
base64	Unary	`binary`	`string`
unbase64	Unary	`string`	`binary`
upper, lower, initcap	Unary	`string`	`string`
substr, substring	Binary	(`string`, `int64`)	`string`	(6)
substr, substring	Ternary	(`string`, `int64`, `int64`)	`string`	(6)
byte_substr, bytesubstring	Ternary	(`binary`, `int32`, `int32`)	`binary`
left, right	Binary	(`string`, `int32`)	`string`
lpad, rpad	Binary	(`string`, `int32`)	`string`
lpad, rpad	Ternary	(`string`, `int32`, `string`)	`string`
concat, concatOperator	2 to 10	`string`	`string`	(7)
binary_string	Unary	`string`	`binary`
split_part	Ternary	(`string`, `string`, `int32`)	`string`
replace	Ternary	(`string`, `string`, `string`)	`string`

(1) bin converts integers to their binary representation as a string. For example, bin(7) = "111".
(2) space creates a string that is a sequence of space whose length is the given integer.
(3) like has a ternary variation where the third parameter is an escape character, making it possible to match patterns with % in them.
(4) locate returns the starting index of the first instance of the first string parameter in the second string parameter. Not that the index is 1-indexed. The optional int32 argument allows you to provide a start position to skip a portion of the string. position is an alias for locate.
(5) The binary variations of ltrim, rtrim, and btrim take a second parameter a string containing the list of characters to trim.
(6) substr returns a substring of the original string, with the integer parameters controlling the position and length. In the binary variation, the second parameter is the length from the start of the string (if positive) or the length from the end of the string (if negative). In the ternary variation, the second parameter is the starting position (1-indexed) and the third parameter is acts as the offset like the second parameter in the binary variation.
(7) concat treats null inputs as empty strings whereas concatOperator returns null if one of the inputs is null

Hash¶

Function names	Arity	Input types	Output type	Notes
hash	Unary	Any	`int32`	(1)
hash32, hash32AsDouble	Unary	Any	`int32`	(2)
hash32	Binary	(Any, `int32`)	`int32`	(2) (3)
hash64, hash64AsDouble	Unary	Any	`int64`	(2)
hash64	Binary	(Any, `int64`)	`int64`	(2) (3)
hashSHA1, sha1, sha	Unary	Any	`string`	(4)
hashSHA256, sha256	Unary	Any	`string`	(5)

(1) Uses hash function from C++ std:hash.
(2) Uses MurmurHash3. hash32 is an alias for hash32AsDouble and hash64 is an alias for hash64AsDouble.
(3) Second parameter is a seed.
(4) sha1 and sha are aliases for hashSHA1.
(5) sha256 is an alias for hashSHA256.
